Aluminium Launder System
Safe metal transfer tailored to your layout
Key Benefits
- Increased safety
- Energy efficient refractory construction
- Adjustable height and length
- Power consumption tracking
Key Features
- Precise temperature control and tracking possible
- Energy efficient refractory construction
- Adjustable height and length
- Power consumption tracking
Applications
A safer alternative to metal transfer via ladle for:
- Low pressure die casting
- High pressure die casting
- Sand and gravity casting
Made-to-measure metal transfer that puts safety first
Transferring metal via forklifts and open ladles is far from ideal when it comes to worker safety and potential metal loss. Transferring liquid aluminium to holding/dosing furnaces, die casting machines and moulding lines via a heated launder system is a safer, more efficient alternative.
We’ll find your optimal fit
Uneven floor? No problem. Adjustable heavy-duty feet mean our Launder System can cope with any variation to ensure even height for smooth metal flow. Complicated layout or short on space? We’ve got that covered too. Available in sizes ranging from 2 – 100 meters and with flanges on either side, our Launder System can be tailored to fit any space.
This capability is important as it also delivers greater furnace size flexibility. For example, if a bigger capacity is needed but only a smaller furnace will fit, our Launder System can be used to position the bale-out pocket separately, closer to the pump location, freeing up valuable space that allows the larger capacity melting furnace to be used.
Keep the heat, save your energy
Gentle heating, pneumatically operated launder lids with tight seals, exacting temperature controls and a blend of clever refractory design features. These all combine to maintain molten aluminium at optimal temperature, eliminating heat loss and utilizing the metal’s own thermal conductivity to keep energy costs down.
Calm transfer means better quality
Smooth transfer is key to melt quality as any turbulence can lead to oxides in the molten aluminium. The StrikoWestofen Launder System is designed with this in mind - eliminating any kind of agitation every step of the way.
Delivered and installed how you need it
The launder is delivered completely fireproof, mechanically and electrically pre-installed. The individual elements are sealed and bolted together according to the layout design. The joints are then filled with small amounts of refractory material to optimize heat retention. No risk of leaks. Just an energy-efficient aluminium transfer system that’s ready to go.
Technical Details & Features/Options
Technical Details
- Available for various lengths and heights
- Pneumatically movable launder covers
- Electrically heated channels (3 heating plates per 3m section with a connected load of 3x 6.2 kW = 18.6 kW).
Features/Options
- Pre-cast refractory shapes/pieces are possible
